1) Combining several global leading display board control technologies, such as grey level code technology, brightness control technology, and nonlinearly rectifying technology
2) Modularization, high resolution and high contrast design, vivid dynamic display
3) Arbitrarily exchanging the display or displaying synchronized video4) Long lifespan, can reach more than 100,000 hours, while the power consumption is lower than one tenth of lamp or neon
5) Economical maintenance and cost saving

Item No./Model	P12
Pixel Composition	2R1G1B
Pixel (mm)	12
Density(dots/m2)	6944
Brightness(cd/m2)	5500
Viewing Distance(m)	≥15
View Angle	H:120°,V55°
Gray Scale(level)	4096
Consumption(Max)	700W/m2
Consumption(Average)	500W/m2
Display Card	DVI card
Control Mode	synchronization Control
Drive Mode	Static constant current
Refresh Rate(HZ)	600
Working Temperature(℃)	-25-- +85℃(for working)
Working Humidity	10%-95%RH
Model Size(mm)	192*192
Cabinet Size(mm):	960*768
Cabinet Dimension(m2)	0.737
Cabinet Weight(KG)	45
Cabinet Resolution(dots)	80*64
Cabinet Material	Steel/Aluminum
Lifespan	100,000 hours
